Aven BD-209-212 - USB Digital Microscope 5M Mighty Scope [10x-200x] with Flex Arm Stand
- Manufacturer: Aven
- Category: Microscopes
- Model # BD-209-212
- Pemro # AVT-4602
Mighty Scope 5M USB Digital Microscope
Convenient and sophisticated, Aven’s Mighty Scope 5M USB Digital Microscope features a plug-and-play USB interface for an easy computer link, as well as adjustable magnification, image and video capture, a large working distance, and a broad magnification range of 10x-50x optical magnification (up to 200x digital magnification). Experience reduced fatigue and increased productivity by viewing clear magnifications on a monitor rather than hunching over traditional microscope eyepieces. The powerful scope also includes dimmable illumination an adjustable stand at no extra cost, as well as advanced software for image capture, annotation, and measurement, freeze frame, and compare mode, making it an essential tool for engineers, scientists, doctors, lab techs, forensic examiners, educators, and more.
High magnification, exceptional clarity
10x to 50x optical magnification and up to 200x digital.Features
- 10x to 50x optical magnification and up to 200x digital
- USB cable plugs into any computer to save, process and share images
- Compatible with Mac and Windows
- Brightness wheel controls 6 LEDs
- Ergonomic design allows comfortable use in either hand
- Single tension knob allows for quick positioning of articulating arm
- Large 240mm working distance
- Glass surface for object placement
- ¼-20 universal camera mount included
- LED on flex arm, on/off and brightness control for additional illumination.
| BD-209-212 Mighty Scope 5m Digital Microscope + 14" Flexible Stand | |
|---|---|
| Contents | 26700-209 - Mighty Scope 5M Digital Microscope 26700-212 - Mighty Scope 14" Flex Stand |
| Mighty Scope 5M USB Digital Microscope | |
| Signal Output | USB 2.0 |
| Magnification based on a 17" monitor | Resolution: 640 x 480 (Max. ~ 95X), Resolution: 1024 x 768 (Max. ~ 150X), Resolution: 2048 x 1536 (Max. ~ 300X) |
| Video format | AVI |
| Gain Control | Automatic |
| Snap Shot Mode | Hardware & Software controls |
| White Balance | Automatic |
| Power Source | 5VDC through USB port |
| O/S | Windows XP, Vista, 7, 8, & 10 | Mac OSX 10.6 or above Note: macOS Catalina and above is not supported |
| Power Consumption | 260mA (AVG) |
| LED Lighting | 6 White LEDs |
| Working Distance | At 10x (112mm), At 20x (42mm), At 30x (19mm), At 40x (8.5mm) |
| Dimensions | Length: 111mm, Diameter: 34.5mm, Cable length: 1.8M (6ft), Metal Stand: Base: 130mm x 140mm, Pole Height: 153mm |
| Weight | 113g |
| Package Contents | Mighty Scope 5M, Metal Stand, Image capture software, Manual |
| Warranty | The Mighty Scope 5M USB Digital Microscope comes with a two year warranty against any manufacturing defects. |
| Base Dimension | 127 x 140mm |
| Adjustable Arm Length | 355mm (14") |
| Weight | 1.1 lb |
| Package Contents | 1 Gooseneck Clamp Metal Base Mounting Hardware ManualMounting Hardware Manual |
