Brady HX-375-2-WT - PermaSleeve HX Heat Shrink Wire Marking Sleeves, White, 0.375" Dia x 2" W, Roll of 1000 Each

Manufacturer: Brady
Category: Wire & Cable Sleeves
Model # HX-375-2-WT (117083)
Pemro # BDZ-4845

$ 1,789.00 See price in cart

Available to Order

Heat-Shrink PermaSleeve® HX Polyolefin (B-7642) Wire Marking Sleeves are 2:1 heat shrinkable, high-temperature rated, highly flame retardant and very flexible.

Supplied roll form in a flattened format on a carrier designed for use with computer driven printers
Meets SAE-AMS-DTL-23053/5 Class 1 & 3, SAE-AS-81531, MIL-STD-2002
Tested per ASTM E162 and ASTM E662
Operating temperature of -40°F to 248°F (-40°C to 120°C)
This roll has i75-series smart properties on the core that when used in the Brady i7500 printer in conjunction with i75-series smart ribbons, eliminates the need to adjust heat, speed , sensor location and mode, eliminates the need to calibrate out blank wasted labels, and warns the operator if a non-approved ribbon is used with this roll.
If this roll is used in Brady i5100 or IP model printers it will function with smart operation in those printers with the exception that the Supply Remaining gauge on the display may be overstated. Contact Brady tech support for further information.
If used in any other 3 inch core printer this roll will function as a manual roll
A ribbon is required to print this material. Use Part Number R6400

Application: Electrical Labeling, Wire and Cable Labeling
Brand Name: Brady®
Color: White
Continuous or Die-cut: Die-cut
Enables Industry Compliance (North America): ASTM D 570, ASTM D 638, ASTM D 792, ASTM D 876, ASTM D 882, ASTM G 21, Halogen Free (DIN VDE 0472 Part 815), MIL-STD-202, SAE-AMS-DTL-23053, SAE-AMS-STD-104 Class 1, SAE-AS-81531, UL Recognized, VW-1
Industry Compliance: UL, MIL-STD
Print Technology: Thermal Transfer
Printable Sides: Single-Side Printable
Printer and Label Applications: Wire & Cable
Printer Compatibility: BBP11, BBP12, BBP72, i6100, i7100, i7500, PR Plus, THT 3" Core Printers
Printer supply or Pre-printed: Printer supply
Quantity per Roll: 1000
Quantity per Row: 1
Recommended Ribbon: i75-R6400, R6400
Recommended Ribbon Series: R4300, R6000HF, R6400, R6600
Ribbon Series: R6600
Sleeve Slits: No
Smart Cell: No
Trade Name: PermaSleeve®
Label Properties: Heat Shrink
Material Properties: Heat-shrinkable
Resistance Properties: Chemical-resistant, Corrosion-resistant, Humidity-resistant, Self-extinguishing, UV-resistant, Weather-resistant
Brady Material Number: B-7642
Finish: Matte
Material: Heat-shrink Polyolefin
Material Type: Polyolefin
Maximum Service Temperature (°C): 120 °C
Maximum Service Temperature (°F): 248 °F
Minimum Service Temperature (°C): -40 °C
Minimum Service Temperature (°F): -40 °F
Service Temperature Range (°C): -40 °C - 120 °C
Service Temperature Range (°F): -40 °F - 248 °F
Shrink Ratio: 2:1
Core Diameter (imperial): 3 in
Core Diameter (metric): 76.20 mm
Diameter as Supplied (imperial): 0.375 in
Diameter as Supplied (metric): 9.53 mm
Dimensions (imperial): 0.645 in H x 2 in W x 0.375 in Dia
Dimensions (metric): 50,80 mm (W) x 16,38 mm (H)
Height (imperial): 0.645 in
Height (metric): 16.38 mm
Maximum Wire Diameter (imperial): 0.32 in
Maximum Wire Diameter (metric): 8.13 mm
Maximum Wire Gauge: 4 AWG
Minimum Wire Diameter (imperial): 0.188 in
Minimum Wire Diameter (metric): 4.78 mm
Minimum Wire Gauge: 8 AWG
Recovered Diameter (imperial): 0.188 in
Recovered Diameter (metric): 4.78 mm
Recovered Wall Thickness (imperial): 0.025 in
Recovered Wall Thickness (metric): 0.64 mm
Roll Width (imperial): 2 in
Roll Width (metric): 50.80 mm
Sleeve Size (imperial): 0.375 in Dia x 2 in W
Sleeve Size (metric): 9.53 mm Dia x 50.80 mm W
Sleeve Width (imperial): 2 in
Sleeve Width (metric): 50.80 mm
Vertical Repeat (imperial): 1 in
Vertical Repeat (metric): 25.40 mm
Web Width (imperial): 3.49 in
Web Width (metric): 88.65 mm
Width (imperial): 2 in
Width (metric): 50.80 mm
Wire Diameter Range (imperial): 0.188 in - 0.32 in
Wire Diameter Range (metric): 4.78 mm to 8.13 mm
Wire Gauge Range: 8 AWG - 4 AWG
EU RoHS Compliant: Yes
CA Prop 65 Warning: Cancer risk from exposure to Antimony Trioxide. See www.P65Warnings.ca.gov
