Brady HX-500-150-WT - PermaSleeve HX Heat Shrink Wire Marking Sleeves, White, 0.5" Dia x 1.5" W, Roll of 500 Each

Manufacturer: Brady
Category: Wire & Cable Sleeves
Model # HX-500-150-WT (117087)
Pemro # BDZ-3566

$ 990.99 See price in cart

Ships in 1 business day

Heat-Shrink PermaSleeve® HX Polyolefin (B-7642) Wire Marking Sleeves are 2:1 heat shrinkable, high-temperature rated, highly flame retardant and very flexible.

Supplied roll form in a flattened format on a carrier designed for use with computer driven printers
Meets SAE-AMS-DTL-23053/5 Class 1 & 3, SAE-AS-81531, MIL-STD-2002
Tested per ASTM E162 and ASTM E662
Operating temperature of -40°F to 248°F (-40°C to 120°C)
This roll has i75-series smart properties on the core that when used in the Brady i7500 printer in conjunction with i75-series smart ribbons, eliminates the need to adjust heat, speed, sensor location and mode, eliminates the need to calibrate out blank wasted labels, and warns the operator if a non-approved ribbon is used with this roll.
If used in any other 3 inch core printer this roll will function as a manual roll
A ribbon is required to print this material. Use Part Number R6406

Application: Electrical Labeling, Wire and Cable Labeling
Brand Name: Brady®
Color: White
Continuous or Die-cut: Die-cut
Enables Industry Compliance (North America): ASTM D 570, ASTM D 638, ASTM D 792, ASTM D 876, ASTM D 882, ASTM G 21, Halogen Free (DIN VDE 0472 Part 815), MIL-STD-202, SAE-AMS-DTL-23053, SAE-AMS-STD-104 Class 1, SAE-AS-81531, UL Recognized, VW-1
Industry Compliance: UL, MIL-STD
Print Technology: Thermal Transfer
Printable Sides: Single-Side Printable
Printer and Label Applications: Wire & Cable
Printer Compatibility: BBP11, BBP12, BBP72, i6100, i7100, i7500, PR Plus, THT 3" Core Printers
Printer supply or Pre-printed: Printer supply
Quantity per Roll: 500
Quantity per Row: 1
Recommended Ribbon: i75-R6400, R6406
Recommended Ribbon Series: R4300, R6000HF, R6400, R6600
Ribbon Series: R6600
Sleeve Slits: No
Smart Cell: No
Trade Name: PermaSleeve®
Label Properties: Heat Shrink
Material Properties: Heat-shrinkable
Resistance Properties: Chemical-resistant, Corrosion-resistant, Humidity-resistant, Self-extinguishing, UV-resistant, Weather-resistant
Brady Material Number: B-7642
Finish: Matte
Material: Heat-shrink Polyolefin
Material Type: Polyolefin
Maximum Service Temperature (°C): 120 °C
Maximum Service Temperature (°F): 248 °F
Minimum Service Temperature (°C): -40 °C
Minimum Service Temperature (°F): -40 °F
Service Temperature Range (°C): -40 °C - 120 °C
Service Temperature Range (°F): -40 °F - 248 °F
Shrink Ratio: 2:1
Core Diameter (imperial): 3 in
Core Diameter (metric): 76.20 mm
Diameter as Supplied (imperial): 0.5 in
Diameter as Supplied (metric): 12.70 mm
Dimensions (imperial): 0.851 in H x 1.5 in W x 0.5 in Dia
Dimensions (metric): 38,10 mm (W) x 21,62 mm (H)
Height (imperial): 0.851 in
Height (metric): 21.62 mm
Maximum Wire Diameter (imperial): 0.45 in
Maximum Wire Diameter (metric): 11.43 mm
Maximum Wire Gauge: 1 AWG
Minimum Wire Diameter (imperial): 0.25 in
Minimum Wire Diameter (metric): 6.35 mm
Minimum Wire Gauge: 6 AWG
Recovered Diameter (imperial): 0.25 in
Recovered Diameter (metric): 6.35 mm
Recovered Wall Thickness (imperial): 0.025 in
Recovered Wall Thickness (metric): 0.64 mm
Roll Width (imperial): 1.5 in
Roll Width (metric): 38.10 mm
Sleeve Size (imperial): 0.5 in Dia x 1.5 in W
Sleeve Size (metric): 12.70 mm Dia x 38.10 mm W
Sleeve Width (imperial): 1.5 in
Sleeve Width (metric): 38.10 mm
Vertical Repeat (imperial): 1.25 in
Vertical Repeat (metric): 31.75 mm
Web Width (imperial): 3.49 in
Web Width (metric): 88.65 mm
Width (imperial): 1.5 in
Width (metric): 38.10 mm
Wire Diameter Range (imperial): 0.25 in - 0.45 in
Wire Diameter Range (metric): 6.35 mm to 11.43 mm
Wire Gauge Range: 6 AWG - 1 AWG
EU RoHS Compliant: Yes
CA Prop 65 Warning: Cancer risk from exposure to Antimony Trioxide. See www.P65Warnings.ca.gov
