Interchangeable Head Type Preset Torque Wrench, 10-50N.m, 100-500kgf.cm, 88.5-442.5lbf.in, 12D Head End Size

• Manufacturer: Tohnichi
• Category: Torque Wrenches
• Model # CSP50N3X12D
• Pemro # TON-2748
$135.00 $ 117.39/each
Available to Order

Interchangeable Head Type Preset Torque Wrench, 10-50N.m, 100-500kgf.cm, 88.5-442.5lbf.in, 12D Head End Size NOTE: Combine with a variety of heads with 12D Head End Size (Sold Separately) Requires torque set prior to use with #930 Adjusting Tool (Sold Separately)

• Interchangeable head and preset torque wrench.
• Preset interchangeable head torque wrenches.
• The set torque cannot be changed without using a special tool (sold separately), preventing the operator from changing torque by mistake.
• A wide selection of interchangeable heads, letting you choose the right one for the task and reduces overall purchasing costs.
• A clear “click” sound signals tightening completion upon reaching the set torque.
• Applicable for international use including the EU region.
• Compliant with calibration procedures of ISO 6789 Type II Class B.
• Tohnichi’s interchangeable head torque wrenches can be used with our interchange head lineup which offers the best selection in the world, making these wrenches ideal for your work.
• See Interchangeable Heads Selection (Sold Separately)
• Note: Heads coordinate with head root dimension of wrench. Model name includes head root dimension after the “X” 8D, 10D, 12D, 15D, 22D. Select heads that have matching root diameter number in the model name.

Specifications / Accuracy ±3%
S.I. Range (N · m]: 10 - 50
Metric Range [kgf · cm/kgf · m]: 100 - 500
American Range [lbf · in]: 100 - 400
Applicable Bolt Common Steel: M10
Applicable Bolt High Tension: (M8)
Max Hand Force [N]: 240
Effective Length [mm]: 208
Overall Length [mm]: 215
Head [mm]: 12
Body [m]: 25.5
Body [n]: 11.2
Body [d]: 20
Body [D]: 34
Weight [kg]: 0.3
